| Model Number |
MB520-KGNN-S00, MB520-WGNN-S00 |
|
| Exterior Color |
Black, White |
|
| Materials – Exterior |
Mesh, Steel, ABS Plastic, Tempered Glass |
|
| Materials – Left Side Panel |
Tempered Glass |
|
| Dimensions (L x W x H) |
499 x 210 x 498mm (Incl. Protrusions), 430 x 210 x 479mm (Body Size) |
|
| Motherboard Support |
Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12″ x 10.7″ motherboards, may impact cable management feature) |
|
|
|
|
|
|
|
| I/O Panel |
1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button |
|
| Included Accessories |
ARGB Fans Hub |
|
| Pre-installed Fans – Front |
3x CF120 ARGB |
|
| Fan Support – Top |
3x 120mm, 2x 140mm |
|
| Fan Support – Front |
3x 120mm, 2x 140mm |
|
| Fan Support – Rear |
1x 120mm |
|
| Radiator Support – Top |
120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm) |
|
| Radiator Support – Front |
120mm, 140mm, 240mm, 280mm, 360mm |
|
| Radiator Support – Rear |
120mm |
|
| Clearance – CPU Cooler |
165mm/6.49″ |
|
| Clearance – PSU |
200mm, (Recommended up to 170mm) |
|
| Clearance – GFX |
410mm/16.1″ |
|
| Dust Filters |
Bottom, Front, Top |
|
|
|
|
|
|
|
|
|
